I am thinking of using such a fan in future impi fanshrouds
Armand
Some thing on my burner
-
IMPI
- Donor
- Posts: 1897
- Joined: Wed Sep 14, 2005 9:01 pm
- What model do you have?: sp2
- Location: Orkney Northwest province
- Has thanked: 1 time
- Been thanked: 78 times
Some thing on my burner
I am thinking of using such a fan in future impi fanshrouds
Armand
Who cares how it's done in California?
(018) 473-0186
-
Dawie
- Fuel Injection
- Posts: 2114
- Joined: Sat Sep 30, 2006 10:25 pm
- What model do you have?: Aircooled, various
- Location: Kaapstadt
- Has thanked: 45 times
- Been thanked: 208 times
Re: Some thing on my burner
Thats interesting! Looks like you are making an adapter to mount the fan from its 4 posts to the alternator shaft. Then you cut a hole where it used to mount on the crankshaft.
This means air now enters from the back. Direction of rotation is therefore still the same.
Nice idea!
This means air now enters from the back. Direction of rotation is therefore still the same.
Nice idea!
Staying Aircooled is so much nicer.
Do'nt assume anything- (While doing fault-finding).
Do'nt assume anything- (While doing fault-finding).
-
AirPower
- Clutch
- Posts: 635
- Joined: Fri Sep 07, 2007 10:39 pm
- What model do you have?: 2008 Buggy
- Location: Vereeniging Transvaal
- Has thanked: 1 time
- Been thanked: 4 times
Re: Some thing on my burner
That looks very good, but I think it's a lot of work
.
You reversed the blades? Never thought that was possible - good one IMPI
Mario
.You reversed the blades? Never thought that was possible - good one IMPI
Mario
Eben said: "ACVW's are made of logic."
Bugger said: "I am happy with the drum brakes when done right as this will be used rarely"
"If it can't be fixed with a hammer, you've got an electrical problem" said by someone.
Bugger said: "I am happy with the drum brakes when done right as this will be used rarely"
"If it can't be fixed with a hammer, you've got an electrical problem" said by someone.
-
vader
- ACVWSA Junkie
- Posts: 6465
- Joined: Mon Sep 19, 2005 9:17 am
- What model do you have?: TieFighter
- Location: Help!I don't know where I am. Its dark & I can hear voices...
- Has thanked: 9 times
- Been thanked: 10 times
Re: Some thing on my burner
'n Boer maak 'n plan!!!!
"My other ride is your SeatCover! & She loves it!"
Sometimes you'r the statue, sometimes your the pigeon.
"Only the dead go free..." Roger Waters.
"You do not understand the power of the DarkSide" Darth Vader.
Sometimes you'r the statue, sometimes your the pigeon.
"Only the dead go free..." Roger Waters.
"You do not understand the power of the DarkSide" Darth Vader.
-
IMPI
- Donor
- Posts: 1897
- Joined: Wed Sep 14, 2005 9:01 pm
- What model do you have?: sp2
- Location: Orkney Northwest province
- Has thanked: 1 time
- Been thanked: 78 times
Re: Some thing on my burner
There are a few reasons for doing a fan for a type four conversion this way.
Using the type four fan means you match vws design more closely.
fans with narrow blades like the type four seems to be more efficient.
I can now run the fan at crank speed.
the fan doesnt have to accelerate faster than the engine like a type one.
the fan being a casting does not need to be welded
it is lighter than a beetle fan.
There is some disadvantages though
it is unproven!
it takes some work to build
it will need a completely new fan housing
I am currently designing a completely new type of conversion.
Why would you ask since the original IMPI conversion works extremely well.....
It is simple
I can.
The original Impi is a bit bulky and with the current trends towards throttle bodies and injectors there is less space in engine compartments.
My vision is to make this conversion as simple and easy to fit that a 6 year old can do it.
Using the type four fan means you match vws design more closely.
fans with narrow blades like the type four seems to be more efficient.
I can now run the fan at crank speed.
the fan doesnt have to accelerate faster than the engine like a type one.
the fan being a casting does not need to be welded
it is lighter than a beetle fan.
There is some disadvantages though
it is unproven!
it takes some work to build
it will need a completely new fan housing
I am currently designing a completely new type of conversion.
Why would you ask since the original IMPI conversion works extremely well.....
It is simple
I can.
The original Impi is a bit bulky and with the current trends towards throttle bodies and injectors there is less space in engine compartments.
My vision is to make this conversion as simple and easy to fit that a 6 year old can do it.
Who cares how it's done in California?
(018) 473-0186
-
eben
- Site Admin
- Posts: 6449
- Joined: Tue Sep 13, 2005 3:40 pm
- What model do you have?: None
- Facebook: www.facebook.com/ebenve
- Location: Fintice, Slovakia
- Has thanked: 91 times
- Been thanked: 54 times
- Contact:
-
AirPower
- Clutch
- Posts: 635
- Joined: Fri Sep 07, 2007 10:39 pm
- What model do you have?: 2008 Buggy
- Location: Vereeniging Transvaal
- Has thanked: 1 time
- Been thanked: 4 times
Re: Some thing on my burner
I think this is the future! In 2 years time if you haven't got an IMPI hurricane cooler, your ride is SO LAST YEAR Porsche - gah bleh - no more.
If the IMPI can keep it cool in the KALAHARI, it will keep it cool ANYWHERE.
Porsche - gah bleh - no more. If the IMPI can keep it cool in the KALAHARI, it will keep it cool ANYWHERE.
Eben said: "ACVW's are made of logic."
Bugger said: "I am happy with the drum brakes when done right as this will be used rarely"
"If it can't be fixed with a hammer, you've got an electrical problem" said by someone.
Bugger said: "I am happy with the drum brakes when done right as this will be used rarely"
"If it can't be fixed with a hammer, you've got an electrical problem" said by someone.
-
calooker
- Donor
- Posts: 4973
- Joined: Wed Sep 14, 2005 9:24 am
- What model do you have?: 77 SP
- Location: Johannesburg
- Has thanked: 5 times
- Been thanked: 98 times
- Contact:
Re: Some thing on my burner
Anothe plus, a slower turning fan will be worth a few extra ponies under foot
There is just so little dudes like you left.
keep up the interest.
There is just so little dudes like you left.
keep up the interest.For what it's worth, ignorance has no limits ......
-
eben
- Site Admin
- Posts: 6449
- Joined: Tue Sep 13, 2005 3:40 pm
- What model do you have?: None
- Facebook: www.facebook.com/ebenve
- Location: Fintice, Slovakia
- Has thanked: 91 times
- Been thanked: 54 times
- Contact:
Re: Some thing on my burner
Sorry I have never worked on a Type 1:
Will your setup mean that the alternator will turn slower than it normally does?
Will your setup mean that the alternator will turn slower than it normally does?
-
Blitzkrieg
- ACVWSA Junkie
- Posts: 10784
- Joined: Wed Mar 07, 2007 10:41 am
- What model do you have?: none
- Location: Johannesburg
- Has thanked: 91 times
- Been thanked: 44 times
Re: Some thing on my burner
It's so good to see SA guys making waves with innovations like these
If it's too low, you're too old
-
vader
- ACVWSA Junkie
- Posts: 6465
- Joined: Mon Sep 19, 2005 9:17 am
- What model do you have?: TieFighter
- Location: Help!I don't know where I am. Its dark & I can hear voices...
- Has thanked: 9 times
- Been thanked: 10 times
Re: Some thing on my burner
Lets see Jake the snake try to keep up with his DTM.... So yesterdays technology...
"My other ride is your SeatCover! & She loves it!"
Sometimes you'r the statue, sometimes your the pigeon.
"Only the dead go free..." Roger Waters.
"You do not understand the power of the DarkSide" Darth Vader.
Sometimes you'r the statue, sometimes your the pigeon.
"Only the dead go free..." Roger Waters.
"You do not understand the power of the DarkSide" Darth Vader.
-
Class 11 streeter
- Oil Stain
- Posts: 142
- Joined: Fri Jan 06, 2006 9:01 am
- What model do you have?: 8.5 Beetles!
- Location: High Desert of California, USA
Re: Some thing on my burner
Geez..........you guys...........such venom.
Armand, what can be done about the reported cavatation the type 4 fan experiences around 4500 RPM?
For a street engine that sees brief full throttle blasts it might not be an issue, but if you can do any high RPM crusing (or racing) it might be worth noting:
http://www.shoptalkforums.com/viewtopic.php?t=68276
Armand, what can be done about the reported cavatation the type 4 fan experiences around 4500 RPM?
For a street engine that sees brief full throttle blasts it might not be an issue, but if you can do any high RPM crusing (or racing) it might be worth noting:
http://www.shoptalkforums.com/viewtopic.php?t=68276
I don't know it all, just enough to be dangerous!
-
calooker
- Donor
- Posts: 4973
- Joined: Wed Sep 14, 2005 9:24 am
- What model do you have?: 77 SP
- Location: Johannesburg
- Has thanked: 5 times
- Been thanked: 98 times
- Contact:
Re: Some thing on my burner
Very interestingClass 11 streeter wrote:Geez..........you guys...........such venom.
Armand, what can be done about the reported cavatation the type 4 fan experiences around 4500 RPM?
For a street engine that sees brief full throttle blasts it might not be an issue, but if you can do any high RPM crusing (or racing) it might be worth noting:
http://www.shoptalkforums.com/viewtopic.php?t=68276
